Product Details:
Payment & Shipping Terms:
|
Material: | 100% Virgin Makrolon | Thickness: | 4mm~8mm |
---|---|---|---|
Max Width: | 2.1m | Length: | As Requested |
UV: | 50um | Guarantee: | 10 Years |
High Light: | uv roof sheeting,double wall polycarbonate panels |
SPECIFICATION OF POLYCARBONATE SUNSHINE SHEETS:
Thickness(mm) | Structure | Weight (g/sqm) |
Min. Bend Radius (mm) |
K value (W/M2K) |
4 | 2-layer |
850 | 700 | 4.1 |
5 | 1000 | 875 | 3.8 | |
6 | 1300 | 1050 | 3.6 | |
8 | 1500 | 1400 | 3.3 | |
10 | 1700 | 1750 | 3 | |
6 | 3-layer |
1400 | 1050 | 3.4 |
8 | 1600 | 1400 | 3.2 | |
10 | 1800 | 1750 | 2.7 | |
12 | 2100 | 2100 | 2.6 | |
14 | 2400 | 2450 | 2.4 | |
16 | 2700 | 2800 | 2.3 |
Technical date of PC sheets:
1, High impact strength: the shock strength is 300 times than glass, and 30 times than PMMA;
2, With 50um UV layer, Anti UV protection and Anti aging.
3, Good light transmission and high heat insulation
4, Fireproof, belong to B1 level fireproof material
5, Good weather resistance, suitable temperature is from - 40 ~120ºC; soften temperature is at 148ºC
6, Elastle stress: 2400 MPa; Tensile stress: 63%; Nominal tensile strain:>50%
APPLICATION OF POLYCARBONATE SHEETS:
1, Building skylights; such as gymnasium, workshop, storehouse etc.
2, Agriculture greenhouse
3, Natatorium coverings
4, Walkway; Carport
5, Indoor partition; Folding screen
6, Furniture; Bathroom
STANDARD COLOR AND LIGHT TRANSMISSION
Thickness(mm) Color |
4 | 5 | 6 | 8 | 10 |
Light transimission | |||||
Clear | 80% | 78% | 76% | 74% | 72% |
Lake Blue | 56% | 54% | 51% | 49% | 48% |
Green | 55% | 52% | 51% | 48% | 46% |
Grass green | 54% | 52% | 50% | 46% | 44% |
Brown | 34% | 32% | 30% | 26% | 23% |
Blue | 33% | 31% | 28% | 25% | 20% |
Opal | 27% | 25% | 22% | 18% | 15% |
Advertising white | 16% | 14% | 12% | 9% | 8% |
HAINING OASIS BUILDING MATERIAL CO.,LTD is an professional manufacturer and exporter of polycarbonae sheets. Established on 2011 and Located at Haining city which is between Shanghai airport and Hangzhou Airport.
We have 3 advanced producing line for polycarbonate sheets. Our factory always focus on quality control, scientific management and R&D, so that we can supply the high quality, competitive price and best service for our clients. That is why our products enjoy good markets in worldwide, such as Latin America, Middle east, Africa and south asisa.
On 2015, we established first branch company at Bogota,Colombia, loacated at Calle 68 #22-43.
On 2016, we set another warehouse in Colombia, the address is Carrera 22#14-60,Bogota.
On 2017, we plan to set more warehouse in another city of Colombia, Such as Cali,Baranquilla.
With “quality first, best credit, clients supreme”, welcome warmly you to inquiry and visit us
PRODUCING AND SHIPMENT OF POLYCARBONATE HOLLOW SHEETS:
